Understanding battery specifications can be confusing because manufacturers use several different units to describe battery performance. Two of the most common are milliamp-hours (mAh) and watt-hours (Wh).
If you have ever compared smartphones, power banks, laptops, drones, rechargeable batteries, or portable power stations, you have probably encountered these measurements.
A Milliamp-Hours to Watt-Hours Calculator simplifies the process of converting between the two units.
The conversion requires three pieces of information:
- Battery capacity in mAh
- Battery voltage in volts
- The conversion formula
The formula is:
Wh = (mAh × V) ÷ 1000
For example, consider a 10,000 mAh battery with a nominal voltage of 3.7 V:
Wh = (10,000 × 3.7) ÷ 1000
Wh = 37 Wh
This article explains how the conversion works, why voltage matters, how to perform the calculation manually, and how to use a free calculator for faster results.
Understanding Milliamp-Hours
Milliamp-hours are commonly abbreviated as mAh.
The unit describes electrical charge capacity.
A milliamp is one-thousandth of an ampere:
1 A = 1,000 mA
An ampere-hour is a unit of electrical charge:
Ah = current × time
Because mAh is one-thousandth of Ah:
1 Ah = 1,000 mAh
Therefore:
5,000 mAh = 5 Ah
This conversion is useful when working with battery specifications.
Understanding Watt-Hours
Watt-hours are abbreviated as Wh.
Wh is a unit of energy.
A watt represents power, while a watt-hour represents energy used or stored over time.
For example:
100 W × 2 hours = 200 Wh
When discussing batteries, Wh can be used to represent the nominal amount of energy stored in a battery.
The Relationship Between mAh, Voltage, and Wh
The key relationship is:
Energy = Charge × Voltage
When charge is expressed in amp-hours:
Wh = Ah × V
Because:
Ah = mAh ÷ 1000
we can substitute it into the equation:
Wh = (mAh ÷ 1000) × V
Therefore:
Wh = mAh × V ÷ 1000
This is the basic equation used by an mAh-to-Wh calculator.
Step-by-Step mAh to Wh Conversion
Let’s convert a battery rated at 8,000 mAh and 3.7 V.
Step 1: Write the formula
Wh = mAh × V ÷ 1000
Step 2: Insert the values
Wh = 8,000 × 3.7 ÷ 1000
Step 3: Multiply
8,000 × 3.7 = 29,600
Step 4: Divide by 1,000
29,600 ÷ 1,000 = 29.6
Final answer
8,000 mAh at 3.7 V = 29.6 Wh
Why the Same mAh Can Produce Different Wh
Suppose you have three batteries, each rated at 10,000 mAh.
Their voltages are:
- Battery A: 3.7 V
- Battery B: 7.4 V
- Battery C: 12 V
The energy values are:
Battery A
10,000 × 3.7 ÷ 1000 = 37 Wh
Battery B
10,000 × 7.4 ÷ 1000 = 74 Wh
Battery C
10,000 × 12 ÷ 1000 = 120 Wh
Although the mAh ratings are identical, the energy capacities are different.
This demonstrates why comparing batteries based solely on mAh can be misleading.
Why Battery Voltage Matters
Voltage represents electrical potential difference.
When converting charge capacity into energy, voltage determines how much energy is associated with a given quantity of charge.
A higher voltage means that the same charge capacity corresponds to more energy.
This is why:
10 Ah × 3.7 V = 37 Wh
while:
10 Ah × 12 V = 120 Wh
The charge is the same, but the energy is different.
Examples for Common Battery Capacities
500 mAh Battery at 3.7 V
500 × 3.7 ÷ 1000 = 1.85 Wh
1,000 mAh Battery at 3.7 V
1,000 × 3.7 ÷ 1000 = 3.7 Wh
2,000 mAh Battery at 3.7 V
2,000 × 3.7 ÷ 1000 = 7.4 Wh
3,000 mAh Battery at 3.7 V
3,000 × 3.7 ÷ 1000 = 11.1 Wh
4,000 mAh Battery at 3.7 V
4,000 × 3.7 ÷ 1000 = 14.8 Wh
5,000 mAh Battery at 3.7 V
5,000 × 3.7 ÷ 1000 = 18.5 Wh
10,000 mAh Battery at 3.7 V
10,000 × 3.7 ÷ 1000 = 37 Wh
20,000 mAh Battery at 3.7 V
20,000 × 3.7 ÷ 1000 = 74 Wh
Using the Calculator for Power Banks
Power banks are one of the most common reasons people need to convert mAh into Wh.
A power bank might be labeled:
10,000 mAh
or:
20,000 mAh
However, the mAh figure normally refers to the battery cells rather than directly representing the energy available at the output port.
Suppose a power bank contains 20,000 mAh of capacity at a nominal 3.7 V cell voltage.
Its nominal stored energy is:
20,000 × 3.7 ÷ 1000 = 74 Wh
The energy delivered to a connected device can be less than 74 Wh because the power bank must convert voltage and experiences electrical losses.
Why Power Banks Have Conversion Losses
A lithium battery cell has a nominal voltage different from the voltage required by many USB devices.
For example, a battery cell may have a nominal voltage around 3.7 V, while USB power may be delivered at 5 V or another supported voltage.
Electronic conversion circuitry is needed.
That conversion is not perfectly efficient.
If the theoretical battery energy is 74 Wh, the usable output energy may be lower.
Therefore, a calculator’s Wh result should not automatically be interpreted as guaranteed output energy.
Using mAh to Wh for Smartphones
Smartphone batteries are commonly advertised using mAh.
For example:
5,000 mAh
Suppose the nominal voltage is 3.85 V.
Then:
Wh = 5,000 × 3.85 ÷ 1000
Wh = 19.25 Wh
This gives an approximate nominal battery energy value.
Battery runtime, however, depends on many other factors.
A smartphone’s energy consumption changes according to:
- Screen brightness
- Cellular signal strength
- Wi-Fi usage
- Processor activity
- Gaming
- GPS
- Bluetooth
- Background applications
- Temperature
- Battery condition
Therefore, Wh cannot directly predict exact smartphone runtime.
Using mAh to Wh for Laptops
Laptop batteries often contain several individual cells.
A battery pack might be listed as:
50 Wh
rather than mAh.
If you want to estimate its equivalent mAh at 11.1 V:
mAh = Wh × 1000 ÷ V
Therefore:
mAh = 50 × 1000 ÷ 11.1
mAh ≈ 4,505 mAh
This illustrates how the same battery can be represented using either Wh or mAh, provided voltage is known.
Reverse Conversion: Wh to mAh
The reverse formula is:
mAh = Wh × 1000 ÷ V
Suppose you have a 100 Wh battery operating at 12 V.
mAh = 100 × 1000 ÷ 12
mAh ≈ 8,333 mAh
This can be useful when a battery specification provides Wh but your project requires an approximate mAh figure.
mAh to Wh for Solar Battery Systems
Battery capacity is important in solar power systems.
Suppose a battery is rated at:
100 Ah
at:
12 V
Convert Ah to Wh:
Wh = Ah × V
Therefore:
100 × 12 = 1,200 Wh
The same battery is approximately:
1.2 kWh
under nominal conditions.
If a battery is instead listed as 100,000 mAh:
100,000 mAh = 100 Ah
and:
100 × 12 = 1,200 Wh
This illustrates why understanding unit conversions is important in renewable-energy projects.
mAh, Wh, and kWh
Large batteries are often described using kilowatt-hours.
The relationship is:
1 kWh = 1,000 Wh
For example:
2,000 Wh = 2 kWh
If a battery has:
20,000 mAh at 12 V
then:
20,000 × 12 ÷ 1000 = 240 Wh
Therefore:
240 Wh = 0.24 kWh
What Happens When Batteries Are Connected in Series?
Battery configuration can affect voltage and capacity.
When identical batteries are connected in series:
- Voltage increases
- Ah capacity generally remains the same
For example, two 3.7 V, 5 Ah cells connected in series produce approximately:
7.4 V, 5 Ah
Their nominal energy is:
7.4 × 5 = 37 Wh
Each individual cell:
3.7 × 5 = 18.5 Wh
Together:
18.5 + 18.5 = 37 Wh
What Happens When Batteries Are Connected in Parallel?
When identical batteries are connected in parallel:
- Voltage remains approximately the same
- Ah capacity increases
For example, two 3.7 V, 5 Ah cells in parallel produce approximately:
3.7 V, 10 Ah
Energy:
3.7 × 10 = 37 Wh
Again, the total nominal energy is approximately the sum of the individual cells.
Important Difference Between Nominal and Actual Energy
A calculator generally performs a mathematical conversion.
It does not automatically account for every physical characteristic of the battery.
Actual battery performance depends on:
- Battery chemistry
- Temperature
- Age
- Discharge rate
- Internal resistance
- Manufacturer specifications
- State of charge
- Battery-management system
- Operating conditions
Consequently, calculated Wh is best viewed as a nominal value when using nominal mAh and voltage ratings.
Common mAh to Wh Conversion Mistakes
Mistake 1: Ignoring Voltage
Trying to convert 10,000 mAh directly into Wh without voltage is incomplete.
Mistake 2: Forgetting the 1,000 Conversion
Because mAh is one-thousandth of Ah, the formula must account for that.
Mistake 3: Using the Wrong Voltage
Use the appropriate nominal voltage for the battery or battery pack being evaluated.
Mistake 4: Assuming Calculated Wh Equals Usable Wh
Real-world losses mean usable energy can be lower.
Mistake 5: Comparing mAh Alone
Different voltage batteries cannot always be fairly compared by mAh alone.
Benefits of a FREE TOOLS mAh to Wh Calculator
An online calculator provides several advantages:
- Fast calculations
- Fewer arithmetic errors
- Easy battery comparisons
- Useful for electronics projects
- Helpful for students
- Convenient for engineers and technicians
- Useful for power-bank comparisons
- Supports energy estimates
- Saves manual calculation time
Frequently Asked Questions
What does mAh mean?
mAh means milliamp-hours and is commonly used to describe battery charge capacity.
What does Wh mean?
Wh means watt-hours and measures energy.
What is the easiest mAh to Wh formula?
Use:
Wh = mAh × voltage ÷ 1000
Is 5,000 mAh equal to 5 Wh?
Not necessarily. At 3.7 V, it is approximately 18.5 Wh.
How many Wh is 10,000 mAh at 3.7 V?
It is:
37 Wh
How many mAh are in 100 Wh?
It depends on voltage.
At 3.7 V:
100 × 1000 ÷ 3.7 ≈ 27,027 mAh
Is Wh more useful than mAh?
For comparing batteries with different voltages, Wh is generally more informative because it represents energy.
Conclusion
Converting milliamp-hours to watt-hours is straightforward when the battery voltage is known.
The formula is:
Wh = (mAh × V) ÷ 1000
A free online Milliamp-Hours to Watt-Hours Calculator can perform this calculation instantly and help users compare batteries, power banks, laptops, smartphones, drones, solar batteries, and other portable power systems.
The key principle to remember is simple: mAh measures charge capacity, while Wh measures energy. Voltage connects the two.
For accurate comparisons, always consider the battery’s voltage and remember that calculated nominal energy may differ from the actual usable energy in a real device.
