Introduction
Battery technology is becoming increasingly important in everyday life. Batteries power smartphones, laptops, electric vehicles, portable power stations, solar systems, RVs, boats, emergency backup systems, and countless electronic devices.
Yet battery specifications can be difficult to understand.
Some batteries are listed in mAh.
Others use Ah.
Portable power stations commonly use Wh.
Large energy-storage systems may use kWh.
Although these units describe related electrical properties, they are not interchangeable without considering voltage.
The FREE TOOLS Watt-Hours to Amp-Hours Calculator provides an easy way to convert watt-hours into amp-hours.
The fundamental formula is:
Ah = Wh ÷ V
This means that if you know the battery’s energy capacity in watt-hours and its nominal voltage, you can calculate its equivalent amp-hour rating.
This guide explores the conversion in detail and explains how to use it for battery sizing, solar power, backup energy, portable devices, and electrical calculations.
What Does Wh Mean?
Wh stands for watt-hour.
It is a unit of energy.
A watt-hour represents one watt of power used for one hour.
For example:
50 W × 2 h = 100 Wh
Therefore, a 50-watt device operating continuously for two hours consumes 100 Wh.
Likewise:
500 W × 2 h = 1,000 Wh
This means it consumes one kilowatt-hour.
What Does Ah Mean?
Ah stands for amp-hour.
It represents electrical charge capacity.
The basic formula is:
Ah = A × h
For example:
A current of 5 amps flowing for 4 hours represents:
5 × 4 = 20 Ah
However, Ah does not include voltage.
That is why two batteries with identical Ah ratings can have very different energy capacities.
Why Voltage Connects Wh and Ah
The electrical power relationship is:
W = V × A
Energy is power multiplied by time:
Wh = W × h
Substitute watts:
Wh = V × A × h
Since:
A × h = Ah
we obtain:
Wh = V × Ah
Rearrange:
Ah = Wh ÷ V
This derivation explains the entire Wh-to-Ah conversion.
The Three Main Battery Formulas
The three formulas you should remember are:
Calculate watt-hours
Wh = Ah × V
Calculate amp-hours
Ah = Wh ÷ V
Calculate voltage
V = Wh ÷ Ah
If you know any two of the three values, you can calculate the third.
Using the Free Calculator
The FREE TOOLS Watt-Hours to Amp-Hours Calculator can be used in three simple steps.
Step 1: Enter Wh
Enter the battery’s watt-hour rating.
Step 2: Enter voltage
Enter the nominal voltage.
Step 3: Calculate
The tool applies:
Ah = Wh ÷ V
and returns the amp-hour result.
Example 1: 300 Wh at 12 V
300 ÷ 12 = 25 Ah
Answer:
25 Ah
Example 2: 750 Wh at 24 V
750 ÷ 24 = 31.25 Ah
Answer:
31.25 Ah
Example 3: 1,500 Wh at 48 V
1,500 ÷ 48 = 31.25 Ah
Answer:
31.25 Ah
Notice something interesting: 750 Wh at 24 V and 1,500 Wh at 48 V both produce 31.25 Ah.
This happens because both represent the same ratio of energy to voltage.
Why Higher Voltage Produces Lower Ah
Suppose energy stays constant at:
2,400 Wh
At 12 V:
2,400 ÷ 12 = 200 Ah
At 24 V:
2,400 ÷ 24 = 100 Ah
At 48 V:
2,400 ÷ 48 = 50 Ah
The energy does not change.
Only the voltage changes.
As voltage increases, the required Ah for the same Wh decreases.
Complete Conversion Table
| Energy | 12 V | 24 V | 36 V | 48 V |
|---|---|---|---|---|
| 120 Wh | 10 Ah | 5 Ah | 3.33 Ah | 2.5 Ah |
| 240 Wh | 20 Ah | 10 Ah | 6.67 Ah | 5 Ah |
| 500 Wh | 41.67 Ah | 20.83 Ah | 13.89 Ah | 10.42 Ah |
| 1,000 Wh | 83.33 Ah | 41.67 Ah | 27.78 Ah | 20.83 Ah |
| 1,500 Wh | 125 Ah | 62.5 Ah | 41.67 Ah | 31.25 Ah |
| 2,000 Wh | 166.67 Ah | 83.33 Ah | 55.56 Ah | 41.67 Ah |
| 3,000 Wh | 250 Ah | 125 Ah | 83.33 Ah | 62.5 Ah |
| 5,000 Wh | 416.67 Ah | 208.33 Ah | 138.89 Ah | 104.17 Ah |
| 10,000 Wh | 833.33 Ah | 416.67 Ah | 277.78 Ah | 208.33 Ah |
How to Calculate Battery Size From Power Consumption
Suppose you have a device that uses:
200 W
and you want it to operate for:
6 hours
Energy requirement:
200 × 6 = 1,200 Wh
Now suppose your battery system is 24 V.
Required nominal Ah:
1,200 ÷ 24 = 50 Ah
Therefore, the theoretical requirement is:
1,200 Wh or 50 Ah at 24 V
Real battery sizing should include appropriate allowances for system efficiency, usable depth of discharge, temperature, battery aging, and other conditions.
Battery Sizing for an Off-Grid System
Imagine an off-grid cabin has the following daily energy requirements:
- Lighting: 300 Wh
- Refrigerator: 1,000 Wh
- Electronics: 500 Wh
- Internet equipment: 200 Wh
Total:
300 + 1,000 + 500 + 200 = 2,000 Wh
Suppose the battery system is 48 V.
Then:
2,000 ÷ 48 = 41.67 Ah
This represents the theoretical nominal Ah requirement for that amount of energy.
A real system would normally require additional capacity because the battery should not necessarily be operated continuously at its theoretical maximum usable limit.
Solar Battery Example
Suppose a solar battery has a capacity of:
7.68 kWh
Convert to Wh:
7.68 × 1,000 = 7,680 Wh
If the battery operates at:
51.2 V
Then:
7,680 ÷ 51.2 = 150 Ah
Therefore:
7.68 kWh at 51.2 V = 150 Ah
This conversion can be helpful when comparing energy-storage systems.
RV Battery Example
Suppose an RV owner has a battery rated at:
2,560 Wh
with a nominal voltage of:
12.8 V
Calculation:
2,560 ÷ 12.8 = 200 Ah
Therefore:
2,560 Wh = 200 Ah at 12.8 V
This can help RV owners compare batteries marketed using either energy or charge capacity.
Marine Battery Example
Suppose a marine battery has:
1,200 Wh
at:
12 V
Then:
1,200 ÷ 12 = 100 Ah
The nominal equivalent is:
100 Ah
However, marine battery selection should also consider starting-current requirements, environmental conditions, battery chemistry, charging systems, and manufacturer specifications.
Emergency Backup Power
Suppose an emergency backup battery contains:
2,000 Wh
At 24 V:
2,000 ÷ 24 = 83.33 Ah
If an emergency load consumes 250 W:
2,000 ÷ 250 = 8 hours
That is a theoretical runtime before accounting for conversion losses and usable-capacity limitations.
If the system has an inverter, the AC output runtime will generally be lower than the ideal calculation.
Why Battery Runtime Estimates Can Be Different
A calculator can provide mathematically correct results while real-world runtime differs.
Reasons include:
Inverter losses
DC-to-AC conversion consumes energy.
Battery efficiency
Batteries do not necessarily deliver all rated energy under every operating condition.
Temperature
Extreme temperatures can affect battery performance.
Aging
Older batteries may provide less capacity than when new.
Discharge rate
Battery capacity can depend on how quickly energy is withdrawn.
Depth of discharge
The system may intentionally reserve part of the battery capacity.
These factors are why battery calculations should be treated as planning estimates rather than guarantees.
Nominal Voltage Versus Actual Voltage
Another important issue is nominal voltage.
A battery described as “12 V” may not remain exactly at 12.000 V during operation.
Its voltage may vary depending on:
- State of charge
- Load
- Temperature
- Battery chemistry
- Charging condition
For a basic conversion, use the nominal voltage associated with the battery’s rating.
Do not automatically replace the nominal voltage with a random voltage reading from a multimeter.
Series Battery Connections
When batteries are connected in series, voltage increases while the Ah capacity of the string generally remains the same for identical batteries.
For example, two identical:
12 V 100 Ah
batteries connected in series produce approximately:
24 V 100 Ah
Energy:
24 × 100 = 2,400 Wh
The same energy can be calculated from the two individual batteries:
12 × 100 × 2 = 2,400 Wh
Parallel Battery Connections
When identical batteries are connected in parallel, voltage remains approximately the same while Ah capacity increases.
Two:
12 V 100 Ah
batteries in parallel provide approximately:
12 V 200 Ah
Energy:
12 × 200 = 2,400 Wh
Again, the total nominal energy is approximately 2,400 Wh.
Series and parallel configurations therefore change the way capacity is expressed.
Why Wh Is Useful for Battery Comparisons
Suppose you are comparing:
12 V 100 Ah
with:
24 V 50 Ah
The first battery:
12 × 100 = 1,200 Wh
The second:
24 × 50 = 1,200 Wh
The Ah values are different, but the nominal energy is the same.
This is why Wh can provide a more meaningful basis for comparing batteries operating at different voltages.
Converting Wh to mAh
Many small electronics use mAh.
The formula is:
mAh = (Wh × 1,000) ÷ V
Example:
Battery:
37 Wh
Voltage:
3.7 V
Calculation:
37 × 1,000 ÷ 3.7
= 10,000 mAh
Therefore:
37 Wh at 3.7 V ≈ 10,000 mAh
This type of conversion is particularly useful for electronics and battery packs.
Converting kWh to Ah
If the energy is expressed in kilowatt-hours:
Wh = kWh × 1,000
Then:
Ah = (kWh × 1,000) ÷ V
Example:
10 kWh at 48 V
First:
10 × 1,000 = 10,000 Wh
Then:
10,000 ÷ 48 = 208.33 Ah
Answer:
208.33 Ah
Converting Ah Back to Wh
The reverse process is equally simple.
Formula:
Wh = Ah × V
Example:
150 Ah at 48 V
Calculation:
150 × 48 = 7,200 Wh
Therefore:
150 Ah at 48 V = 7.2 kWh
This demonstrates that the Wh-to-Ah calculator is based on a reversible relationship.
When Should You Use a Wh to Ah Calculator?
The calculator can be useful when:
- Comparing battery specifications
- Designing a solar system
- Planning RV power
- Comparing portable power stations
- Understanding electric bicycle batteries
- Converting laptop battery specifications
- Calculating backup power
- Planning battery banks
- Checking manufacturer specifications
- Studying electrical engineering concepts
- Estimating battery requirements
Who Can Benefit From This Calculator?
Homeowners
Useful for understanding home backup batteries and solar energy storage.
Solar installers
Useful for converting between different battery specifications during preliminary calculations.
RV owners
Useful when comparing battery banks and portable power systems.
Electronics enthusiasts
Useful when converting battery specifications for projects.
Students
Useful for learning the relationship between voltage, current, energy, and charge.
Engineers and technicians
Useful for quick preliminary calculations and specification checks, although detailed engineering design should use complete manufacturer data and applicable standards.
Frequently Asked Questions
What is the Watt-Hours to Amp-Hours formula?
Ah = Wh ÷ V
How many amp-hours are 1,200 Wh at 12 V?
1,200 ÷ 12 = 100 Ah
How many amp-hours are 1,200 Wh at 24 V?
1,200 ÷ 24 = 50 Ah
How many amp-hours are 1,200 Wh at 48 V?
1,200 ÷ 48 = 25 Ah
How many Ah are 5 kWh at 48 V?
5 kWh = 5,000 Wh.
5,000 ÷ 48 = 104.17 Ah
Can Wh be converted to mAh?
Yes.
mAh = (Wh × 1,000) ÷ V
Does battery chemistry change the mathematical formula?
The basic nominal relationship remains:
Wh = Ah × V
However, practical battery behavior and usable capacity can vary significantly by chemistry and operating conditions.
Is a higher Ah battery always better?
No. Voltage must also be considered.
For example:
100 Ah × 12 V = 1,200 Wh
while:
100 Ah × 48 V = 4,800 Wh
The second battery has four times the nominal energy.
Why does the same Wh rating produce different Ah values?
Because:
Ah = Wh ÷ V
Increasing voltage reduces the amp-hour value for the same energy.
Tips for Getting Accurate Results
Use the correct Wh value
Check the manufacturer’s specification.
Use nominal voltage
Do not substitute an arbitrary instantaneous voltage.
Convert kWh first
Multiply kWh by 1,000 to obtain Wh.
Check mAh versus Ah
Divide mAh by 1,000 to get Ah.
Consider usable capacity
Rated energy is not always identical to usable energy.
Consider efficiency
Inverters and other power electronics introduce losses.
Check battery documentation
For safety-critical applications, manufacturer specifications and qualified electrical professionals should take precedence over a basic online calculator.
Quick Reference Formula Sheet
Watt-hours
Wh = W × h
Amp-hours
Ah = A × h
Battery energy
Wh = Ah × V
Watt-hours to amp-hours
Ah = Wh ÷ V
Amp-hours to watt-hours
Wh = Ah × V
Watt-hours to milliamp-hours
mAh = (Wh × 1,000) ÷ V
Kilowatt-hours to watt-hours
Wh = kWh × 1,000
Watt-hours to kilowatt-hours
kWh = Wh ÷ 1,000
Final Thoughts
The FREE TOOLS Watt-Hours to Amp-Hours Calculator is a simple but valuable tool for anyone working with batteries and electrical energy.
The central formula is:
Ah = Wh ÷ V
Once you understand this relationship, battery specifications become much easier to interpret.
A battery rated at 1,200 Wh could be:
- 100 Ah at 12 V
- 50 Ah at 24 V
- 33.33 Ah at 36 V
- 25 Ah at 48 V
The energy remains approximately the same, while the Ah rating changes according to voltage.
This is why both Wh and Ah should always be considered together with voltage when comparing batteries.
Whether you are planning a solar battery bank, evaluating a portable power station, comparing RV batteries, working on an electronics project, or studying electrical calculations, the FREE TOOLS Watt-Hours to Amp-Hours Calculator provides a fast way to make the conversion.
Enter the watt-hours, enter the nominal voltage, and calculate the amp-hours instantly.
